A good friend who is also a dev on the Amiga OS 3.2 series asked me to get the Amiga ROM Kernel Reference Manual Libraries 3rd edition added to the site. It has been laying in my stack for years now.
This book is heavy with loads of pages, 980 to be exact.
As I wanted to keep the book, I scanned this on a flatbed scanner rather than my document scanner.
Total work on this was more than 11 hours. I hope you’ll enjoy it.
Once again the awesome team of Camilla Boemann and Jason Stead has given us more great stuff in this new (but yet WIP) Reference Manual.
ROM Kernel Reference Manual – The Coveted Addendum – Changes & Additions.
This is the second wip-release Camilla Boemann and Jason Staed have released.
I’m feeling very nostalgic just looking at the front page, specially as I didn’t expect to see a cover so soon.
One can really see how dedicated they are in their work.
Again a huge thank you, to both!
What’s really inside the Commodore 64, thanks to John Watson.
Datasheets for the following chips.
Unfortunately the quality is not it’s usual self, getting something better might prove very difficult.
Thanks to Ove Mejlgaard/ElFi.
* 2009 256K ROM
* 2316 STATIC READ ONLY MEMORY (2048X8)
* 2332 STATIC READ ONLY MEMORY (4096X8)
* 2364 STATIC READ ONLY MEMORY (8192X8)
* 4050/1 BIT DYNAMIC RAM
* 6500/1 ONE CHIP MICROCOMPUTER
* 6508 MICROPROCESSOR WITH RAM AND I/O
* 6509 MICROPROCESSOR WITH MEMORY MANAGEMENT
* 6520 PERIPHERAL ADAPTER
* 6523 TRI-PORT INTERFACE
* 6525 TRI-PORT INTERFACE
* 6526 COMPLEX INTERFACE ADAPTER (CIA )
* 6529 SINGLE PORT INTERFACE
* 6530 MEMORY, I/O TIMER ARRAY
* 6532 MEMORY, 1/0 , TIMER ARRAY
* 6545-1 CRT CONTROLLER (CRTC)
* 6551 ASYNCHRONOUS COMMUNICATION INTERFACE ADAPTER
* 6560/1 VIDEO INTERFACE CHIP
* 6566/6/7/8/9 VIDEO CONTROLLER
* 6581 SOUND INTERFACE DEVICE (SID)
* 7360 HIGH-RESOLUTION DISPLAY
* 7501 MICROPROCESSOR
* 7563 80-COLUMN DISPLAYCHIP
* 7700 SIGNETICSDEVICE
* 7701 VIDEO CHIPS (6566/7/8/9)
* 7702 FOR USE IN PLACE OF 7700 & 7701
* 7703 GLUE CHIP CONVERSION
* 7706 SPEECH INTERFACE CHIP
* 7707-14 TTL
* 8005 128K ROM
* 8562 VIDEO INTERFACE CHIP
* 8580 SOUND INTERFACE DEVICE (SID)
* 8360,8501,8563,8700,8701,8702,8703,8706,8707-14
The CBM 40/80 Column Kernal (PET), thanks to Ove Mejlgaard.
This is a photocopy and should be replaced if possible.
Amiga ROM Kernel Reference Manual: Libraries and Devices, thanks to DDHF.
ROM listing for Commodore 2030/2040 Dual Floppy File Controller (6502), Disk Operating System Version 2.1. Corresponds to MOS 6332 ROMs #901486-11,-12 and -13. Thanks to Ove Mejlgaard.
Assembly source code listing for PET BASIC Version 2.2 for Commodore 10/16/64. Thanks to Ove Mejlgaard for the document.
Some errors are seen from page 82, however these are present on the source printout so this was not a scanning error.
Added ‘Commodore Source Code Listing for C128 ROMs’ with thanks to Ove Mejlgaard.
Contains listings for ROMs with P/N 318018-02, 318019-02 and 318020-03.
